Iris Series (High-Brightness)
MicroLED
Excellent picture quality
Cable Free Design
Energy saving
Full Flip-Chip COB
Seamless splicing
High protection
Lightweight design with a perfect aspect ratio
Ultra-thin 31mm cabinet, just 4.5kg in weight. Get maximum flexibility as you can splice FHD, UHD and FUHD screens at random!
Dual backup,multiple protection
The receiver card and power supply both support dual backups. If the signal receiver or power module fails, it will automatically switch to the backup module to ensure normal display and provide protection for continuous display.
Dark as ink,smooth as a mirror
The module adopts a matte black finish treatment, ensuring a uniform and consistent ink-like colour.
The customized connectors combined with the magnets on the cabinet allow the module to adjust in three axes and six directions, ensuring a perfectly flat screen surface.
The best picture quality, the greatest display
Full flip-chip COB technology brings an all-around improvement to the picture display, with a higher contrast ratio and a wider colour gamut to give you the ultimate visual enjoyment.
Maintenance as easy as ABC
Using a suction cup tool, the module can be easily dismantled and installed, improving maintenance efficiency. No maintenance channel is required, saving installation space.
Unique hole positions,various installation options
The four corners of the cabinet have front and rear bi-directional mounting holes, supporting fixed mounting, wall mounting and other installation options, suitable for various installation environments.
Specifications
Iris Series Micro LED(high brightness)
C63-09VF(H)
C63-12VF(H)
C63-12VF(P)
C63-15VF(H)
  • Model
  • Pixel Pitch(mm)
  • Resolution
  • Panel Technology
  • Unit Size (W × H × Dmm)
  • Surface Treatment
  • Brightness(nits)
  • Contrast Ratio
  • Colour Temperature(K)
  • Frame Rate(Hz)
  • Refresh Rate(Hz)
  • Working Voltage
  • Power Consumption Max(W/m²)
  • Power Consumption AVG (W/m²)
  • Viewing Angle(H./V.)
  • Lifetime(Hours)
  • Operating Temp(℃)
  • Humidity Range(%RH)
  • Unit Weight(kg)
  • C63-09VF(H)
  • P0.9375mm
  • 640 x 360
  • Full flip-chip COB
  • 600*337.5*31mm
  • Matte black finish
  • 1000
  • ≤1000000: 1
  • 3000K~9300K(adjustable)
  • 60
  • 3840
  • AC: 100V~240V,50/60Hz
  • 200
  • 70
  • 170°/170°
  • 100000
  • -10 ~ +50
  • 10 ~ 80
  • 4.5
  • C63-12VF(H)
  • P1.25
  • 480 x 270
  • Full flip-chip COB
  • 600*337.5*31mm
  • Matte black finish
  • 1000
  • ≤1000000: 1
  • 3000K~9300K(adjustable)
  • 60
  • 3840
  • AC: 100V~240V,50/60Hz
  • 250
  • 85
  • 170°/170°
  • 100000
  • -10 ~ +50
  • 10 ~ 80
  • 4.5
  • C63-12VF(P)
  • P1.25
  • 480 x 270
  • Full flip-chip COB
  • 600*337.5*31mm
  • Matte black finish
  • 1000
  • ≤1000000: 1
  • 3000K~9300K(adjustable)
  • 60
  • 3840
  • AC: 100V~240V,50/60Hz
  • 250
  • 85
  • 170°/170°
  • 100000
  • -10 ~ +50
  • 10 ~ 80
  • 4.5
  • C63-15VF(H)
  • P1.5625
  • 384 x 216
  • Full flip-chip COB
  • 600*337.5*31mm
  • Matte black finish
  • 1000
  • ≤1000000: 1
  • 3000K~9300K(adjustable)
  • 60
  • 3840
  • AC: 100V~240V,50/60Hz
  • 250
  • 85
  • 170°/170°
  • 100000
  • -10 ~ +50
  • 10 ~ 80
  • 4.5
