CMS Series

High Contrast

Flip-Chip COB

IP65 Protection

Energy-Efficient

Full Flip-Chip COB Process

Adopting full flip-chip COB process panels with a surface hardness of up to 4H, providing multi-protection against moisture, dust, and impact.

Matte Finish, Uniform Deep Black

The module surface is treated with a matte finish, ensuring uniform and consistent deep black color.

Immersive Experience, True Colour Perception

Carefully selected PWM driver ICs for more natural grayscale transitions, delivering an ultra-wide colour gamut and realistic visuals.

Magnetic Mounting Design, Ultimate Flatness

The rear features a magnetic mounting design, allowing independent adjustment of magnet height to ensure precise and even flatness across the display surface.

Standardized Dimensions

The module utilizes a standardized 320x160mm size.

Broad Compatibility with Various Cabinet Sizes

Compatible with different die-cast cabinet sizes such as 320*480, 640*480, and 960*480.

Specifications

CMS Series

UMC3216-12VA

UMC3216-15VA

UMC3216-18VA

Module
Module Size(WxHxD)/(mm)
Pixel Pitch (mm)
Panel Technology
Module Resolution
Gray Scale(Bits)
Brightness(cd/m²)
Viewing Angle(H./V.)
Colour Temperature(K)
Refresh Rate (Hz)
Power Consumption Max(W/m²)
Power Consumption Typical(W/m²)
Working Voltage
Lifetime (Hours)
Operating Temp (°C)
Operating Humidity (%RH)

UMC3216-12VA
320 x 160
P1.25
COB
256 x 128
13
600
170°/170°
3000 ~ 9300(adjustable)
3840
450
150
AC:100V~240V,50/60Hz
100,000
-10 ~ +50
10 ~ 80

UMC3216-15VA
320 x 160
P1.5385
COB
208 x 104
13
600
170°/170°
3000 ~ 9300(adjustable)
3840
450
150
AC:100V~240V,50/60Hz
100,000
-10 ~ +50
10 ~ 80

UMC3216-18VA
320 x 160
P1.86
COB
172 x 86
13
600
170°/170°
3000 ~ 9300(adjustable)
3840
450
150
AC:100V~240V,50/60Hz
100,000
-10 ~ +50
10 ~ 80

Related Downloads

CMS Series

0.5MB

2023-04-17
