Iris Air-S Series

Iris Air-S Series
LED STANDARD PANEL

8K Ultra HD resolution

Spliceable 4K/8K visuals.

16:9 aspect ratio

Optimum viewing ratio for human eyes.

Seamless surface

Seamless connection between modules and cabinets

Lightweight design

4kg cabinet

Artistic appearance

16:9 aspect ratio, 4.5kg lightweight design,
31mm ultra-slim cabinet.

Wide pixel pitch range for UHD/FUHD visual

Offering four different pixel pitches, the Iris Air-S can be spliced to achieve standard UHD/FUHD resolution displays for an exceptional visual experience.

Flexible splicing, seamless display

The Iris Air-S adopts a high-precision CNC machined die-cast aluminium cabinet, combined with a six-way automatic module adjustment connector and a large module design, which easily achieves seamless splicing and ultra-high flatness.

Point-by-point calibration technology for trouble-free module replacement

The use of point-by-point colour correction technology greatly enhances the display effect, and the module supports the calibration data storage function, so that there is no difference in the display after replacing the module with a new one.

Multiple applications

Command Center

Digital Advertising

Lobby

Exhibition

Digtal Advertising

Digtal Advertising

Specifications

Iris Air-S Series

U63-12VT

U63-15VT

U63-18VT

U63-25VT

Model
Pixel Pitch(mm)
Resolution
Panel Technology
Unit Size(W x H x D)
Brightness(nits)
Contrast Ratio
Color Tempeature(K)
Frame Rate(Hz)
Refresh Rate(Hz)
Working Voltage
Power Consumption Max(W/m²)
Power Consumption AVG (W/m²)
Viewing Angle(H./V.)
Lifetime(Hours)
Operating Temp(°C)
Humidity Range(%RH)
Unit Weight(kg)

U63-12VT
P1.25mm
480x270
SMD
600 x 337.5 x31
800
4000:1
3000 ~ 9300(adjustable)
60
3840
AC:100V~240V50/60Hz
600
200
160°/160°
100000
-10~+50
10~80
4.5

U63-15VT
P1.5mm
384*216
SMD
600 x 337.5 x31
800
4000:1
3000 ~ 9300(adjustable)
60
3840
AC:100V~240V50/60Hz
600
200
160°/160°
100000
-10~+50
10~80
4.5

U63-18VT
P1.8mm
320*180
SMD
600 x 337.5 x31
700
4000:1
3000 ~ 9300(adjustable)
60
3840
AC:100V~240V50/60Hz
500
170
160°/160°
100000
-10~+50
10~80
4.5

U63-25VT
P2.5mm
240*135
SMD
600 x 337.5 x31
600
4000:1
3000 ~ 9300(adjustable)
60
3840
AC:100V~240V50/60Hz
500
170
160°/160°
100000
-10~+50
10~80
4.5
