IRIS-S COB All-in-One

IRIS-S COB All-in-One
108”/135”/163”/216”

Screen Mirroring

Interactive Meeting

Touch Control

COB Panel

UHD large size, immersive conference experience

Available in various size options: 108”, 135”, 163”, 216”

High-precision touch control, inspiration at your fingertips

AvaSupports touch control (compatible with dual systems) using highly precise infrared touch technology. Touch accuracy of ±2mm ensures flexible and accurate interactive operations, enabling natural and smooth writing for more convenient and efficient meetings.

All-in-one design, one display meets all needs

Built-in Android 11.0 system
Octa-core processor
Equipped with various input and output ports
Dual-channel surround sound
External cameras, microphones and other devices can be connected

Dual operating system (optional)
Windows/Android free switch

Multiple display modes, adaptive for all scenarios

Tailored for different meeting environments, offering Standard, Soft, Cinema, and Video modes for optimal display in any setting.

Flexible installation, easy maintenance

Support wall mounting and mobile stand-mounting.
Full front maintenance design allows for convenient installation and service.

Specifications

IRIS-S COB ALL-IN-ONE

S108COBVT-FSN

SR108COBVT-FSN

S135COBVT-FSN

SR135COBVT-FSN

S135COBVT-USN

SR135COBVT-USN

S163COBVT-FSN

SR163COBVT-FSN

S163COBVT-USN

SR163COBVT-USN

S216COBVT-USN

Model
Display Size
Resolution
Aspect Ratio
Touch control
Overal Dimensions (W x H x D mm)
Actual Screen Dimensions (W x H x D mm)
Installation Method
Refresh Rate(Hz)
Brightness(nits)
Gray Scale(Bit)
Contrast Ratio
Viewing Angle(H./V.)
Maintenance Method
Operating System
Working Voltage
Power Consumption Max(W)
Power Consumption AVG(W)
Storage Temp(°C)
Operating Temp(°C)
Storage Humidity(%RH)
Humidity Range(%RH)

S108COBVT-FSN
108"
1920*1080
16:9
No
2425 x 1487 x 45
Bottom Thickness 59.5mm
2400 x 1350mm
Mobile Stand/Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
1200
400
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

SR108COBVT-FSN
108"
1920*1080
16:9
Infrared touch
2425 x 1487 x 45
Bottom Thickness 59.5mm
2400 x 1350mm
Mobile Stand/Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
1200
400
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

S135COBVT-FSN
135”
1920*1080
16:9
No
3025 x 1825 x 45
Bottom Thickness 59.5mm
3000 x 1687.5mm
Mobile Stand/Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
1850
620
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

SR135COBVT-FSN
135”
1920*1080
16:9
Infrared touch
3025 x 1825 x 45
Bottom Thickness 59.5mm
3000 x 1687.5mm
Mobile Stand/Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
1850
620
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

S135COBVT-USN
135”
3840*2160
16:9
No
3025 x 1825 x 45
Bottom Thickness 59.5mm
3000 x 1687.5mm
Mobile Stand / Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
2580
860
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

SR135COBVT-USN
135”
3840*2160
16:9
Infrared touch
3025 x 1825 x 45
Bottom Thickness 59.5mm
3000 x 1687.5mm
Mobile Stand / Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
2580
860
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

S163COBVT-FSN
163”
1920*1080
16:9
No
3625 x 2162 x 45
Bottom Thickness 59.5mm
3600 x 2025mm
Mobile Stand/Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
2450
820
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

SR163COBVT-FSN
163”
1920*1080
16:9
Infrared touch
3625 x 2162 x 45
Bottom Thickness 59.5mm
3600 x 2025mm
Mobile Stand / Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
2450
820
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

S163COBVT-USN
163”
3840*2160
16:9
No
3625 x 2162 x 45
Bottom Thickness 59.5mm
3600 x 2025mm
Mobile Stand / Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
2750
920
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

SR163COBVT-USN
163”
3840*2160
16:9
Infrared touch
3625 x 2162 x 45
Bottom Thickness 59.5mm
3600 x 2025mm
Mobile Stand / Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
2750
920
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90

S216COBVB-USN
216”
3840*2160
16:9
No
4825 x 2837 x 45
Bottom Thickness 59.5mm
4800 x 2700mm
Wall Mounting
3840
600
22
1000000:1
170°/170°
Front
Android 11.0，8+128G
AC:100V~240V, 50/60Hz
4600
1550
-20 ~ 60
-10 ~ 50
10 ~ 90
10 ~ 90
