55”Discovery-Ultra Series MIP Panel

55”Discovery-Ultra Series MIP Panel
Beyond Limits Beyond Expectations

Ultra-large Size, Slim Design

1212x681.75mm Cabinet size, with 39mm thickness and 19kg in weight.

MIP Technology Leads the Display Revolution

Ultimate color accuracy, flawlessly reproducing every authentic detail.

Three-axis Six-way Adjustment

The customized connectors combined with the magnets on the cabinet allow the module to adjust in three axes and six directions, ensuring a perfectly flat screen surface.

22bit+High Grayscale Resulting in More Natural Detail Transition

Adopting integrated row-column driver IC to ensure high-quality display at low brightness and higher grayscale up to 22bit+ in high grayscale mode.

Dark as Ink, Smooth as a Mirror

The module adopts a matte black finish treatment，ensuring a uniform and consistent ink-like colour.

Bi-directional Front and Rear Mounting for Easy Installation

The cabinet supports front and rear bi-directional installation, suitable for various installation environments.

Receiver Card Backup, Multiple Protection

The receiver card supports dual backup. If the signal receiver fails, it will automatically switch to the backup receiver card to ensure normal display and provide protection for continuous display.

5Gb/s High Speed Transmission

A single network cable enables ultra-high transmission rates for a streamlined, sleek cabling setup.

Full Front Maintenance Design

No need to reserve maintenance channel, saving installation space, more convenient installation and maintenance.

Specifications

55”Discovery-Ultra Series MIP Panel

MC6-06VA

MC6-09VA

Model
Pixel Pitch(mm)
Resolution
Panel Technology
Unit Size(W x H x Dmm)
Surface Treatment
Brightness(nits)
Contrast Ratio
Color Temperature(K)
Frame Rate(Hz)
Refresh Rate(Hz)
Working Voltage
Power Consumption Max(W/m2)
Power Consumption AVG(W/m2)
Lifetime(Hours)
Operating Temp(°C)
Humidity Range(%RH)
Unit Weight(kg)

MC6-06VA
P0.63125
1920*1080
MIP
1212 x681.75 x39
Matte black fnish
1000
Up to 1, 000, 000:1
7500(Adjustable)
60/120
3840/7680
AC:100~240V,50/60Hz
450
150
100000
-10~+50
10-80(Non-condensing)
19

MC6-09VA
P0.9469
1280*720
MIP
1212 x681.75 x39
Matte black fnish
900
Up to 1, 000, 000:1
7500(Adjustable)
60
3840
AC:100~240V,50/60Hz
320
110
100000
-10~+50
10-80(Non-condensing)
19
