OMS Series Outdoor LED Module Solution

OMS Series Outdoor LED Module Solution
P2.5/P3.076/P4/P5/P6.67/P8/P10

High Brightness

Brightness up to 5500nits, not afraid of outdoor bright light.

IP65 Protection

Maintains normal use in high temperature and rainy conditions.

Full-color Display

High contrast ratio and high refresh rate for high-quality image display.

Internal Routing Design

Clean and beautiful appearance.

Specifications

OMS Series Outdoor LED Module Solution

DM3216-2P5VD

DM3216-3PVD

DM3216-4PVD

DM3216-5PVD

DM3216-6P6VD

DM3216-8PVD

DM3216-10PVD

Model
Pixel Pitch(mm)
Model Resolution
LED Type
Module Size(W x H m)
Viewing Angle(H./V.)
IP Rate
Brightness(nits)
Contrast Ratio
Refresh Rate(Hz)
Colour Temperature(K)
Power Consumption Max (W/m²)
Average Power Consumption(W/m²)
Lifetime(Hours)
Operating Temp(°C)
Operating Range(%RH)

DM3216-2P5VD
P2.5
128*64
SMD1415
320 x 160
140°/140°
IP65
4500
5000 : 1
3840
3000 - 9300(adjustable)
850
285
100000
-20 - 50
10 - 90

DM3216-3PVD
P3.076
104*52
SMD1921
320 x 160
140°/140°
IP65
4500
5000 : 1
1920
3000 - 9300(adjustable)
850
285
100000
-20 - 50
10 - 90

DM3216-4PVD
P4
80*40
SMD1921
320 x 160
140°/140°
IP65
5000
5000 : 1
1920
3000 - 9300(adjustable)
850
285
100000
-20 - 50
10 - 90

DM3216-5PVD
P5
64*32
SMD1921
320 x 160
140°/140°
IP65
5000
5000 : 1
1920
3000 - 9300(adjustable)
850
285
100000
-20 - 50
10 - 90

DM3216-6P6VD
P6.67
48*24
SMD2727
320 x 160
140°/140°
IP65
5000
5000 : 1
1920
3000 - 9300(adjustable)
850
285
100000
-20 - 50
10 - 90

DM3216-8PVD
P8
40*20
SMD3535
320 x 160
140°/140°
IP65
5000
5000 : 1
1920
3000 - 9300(adjustable)
800
270
100000
-20 - 50
10 - 90

DM3216-10PVD
P10
32*16
SMD3535
320 x 160
140°/140°
IP65
5500
5000 : 1
1920
3000 - 9300(adjustable)
800
270
100000
-20 - 50
10 - 90
