IRIS-S COB All-in-One
108”/135”/163”/216”
Screen Mirroring
Interactive Meeting
Touch Control
COB Panel
UHD large size, immersive conference experience


Available in various size options: 108”, 135”, 163”, 216”
High-precision touch control, inspiration at your fingertips
AvaSupports touch control (compatible with dual systems) using highly precise infrared touch technology. Touch accuracy of ±2mm ensures flexible and accurate interactive operations, enabling natural and smooth writing for more convenient and efficient meetings.
All-in-one design, one display meets all needs


  • Built-in Android 11.0 system
  • Octa-core processor
  • Equipped with various input and output ports
  • Dual-channel surround sound
  • External cameras, microphones and other devices can be connected


Dual operating system (optional)
Windows/Android free switch


Multiple display modes, adaptive for all scenarios
Tailored for different meeting environments, offering Standard, Soft, Cinema, and Video modes for optimal display in any setting.
Flexible installation, easy maintenance


  • Support wall mounting and mobile stand-mounting.
  • Full front maintenance design allows for convenient installation and service.


Specifications
IRIS-S COB ALL-IN-ONE
S108COBVT-FSN
SR108COBVT-FSN
S135COBVT-FSN
SR135COBVT-FSN
S163COBVT-FSN
SR163COBVT-FSN
S216COBVT-USN
  • Model
  • Display Size
  • Resolution
  • Aspect Ratio
  • Touch control
  • Overal Dimensions (W x H x D mm)
  • Actual Screen Dimensions (W x H x D mm)
  • Installation Method
  • Refresh Rate(Hz)
  • Brightness(nits)
  • Gray Scale(Bit)
  • Contrast Ratio
  • Viewing Angle(H./V.)
  • Maintenance Method
  • Operating System
  • Working Voltage
  • Power Consumption Max(W)
  • Power Consumption AVG(W)
  • Storage Temp(°C)
  • Operating Temp(°C)
  • Storage Humidity(%RH)
  • Humidity Range(%RH)
  • S108COBVT-FSN
  • 108"
  • 1920*1080
  • 16:9
  • No
  • 2410 x 1480 x 31
    Bottom Thickness 47mm
  • 2400 x 1350mm
  • Mobile Stand/Wall Mounting
  • 3840
  • 600
  • 22
  • 1000000:1
  • 170°/170°
  • Front
  • Android 11.0,4+32G
  • AC:100V~240V, 50/60Hz
  • 1200
  • 400
  • -20 ~ 60
  • -10 ~ 50
  • 10 ~ 90
  • 10 ~ 90
  • SR108COBVT-FSN
  • 108"
  • 1920*1080
  • 16:9
  • Infrared touch
  • 2423 x 1487 x 45
    Bottom Thickness 47mm
  • 2400 x 1350mm
  • Mobile Stand/Wall Mounting
  • 3840
  • 600
  • 22
  • 1000000:1
  • 170°/170°
  • Front
  • Android 11.0,4+32G
  • AC:100V~240V, 50/60Hz
  • 1200
  • 400
  • -20 ~ 60
  • -10 ~ 50
  • 10 ~ 90
  • 10 ~ 90
  • S135COBVT-FSN
  • 135”
  • 1920*1080
  • 16:9
  • No
  • 3010 x 1817.5 x 31
    Bottom Thickness 47mm
  • 3000 x 1687.5mm
  • Mobile Stand/Wall Mounting
  • 3840
  • 600
  • 22
  • 1000000:1
  • 170°/170°
  • Front
  • Android 11.0,4+32G
  • AC:100V~240V, 50/60Hz
  • 1850
  • 620
  • -20 ~ 60
  • -10 ~ 50
  • 10 ~ 90
  • 10 ~ 90
  • SR135COBVT-FSN
  • 135”
  • 1920*1080
  • 16:9
  • Infrared touch
  • 3023 x 1824 x 45
    Bottom Thickness 47mm
  • 3000 x 1687.5mm
  • Mobile Stand/Wall Mounting
  • 3840
  • 600
  • 22
  • 1000000:1
  • 170°/170°
  • Front
  • Android 11.0,4+32G
  • AC:100V~240V, 50/60Hz
  • 1850
  • 620
  • -20 ~ 60
  • -10 ~ 50
  • 10 ~ 90
  • 10 ~ 90
  • S163COBVT-FSN
  • 163”
  • 1920*1080
  • 16:9
  • No
  • 3610 x 2155 x 31
    Bottom Thickness 47mm
  • 3600 x 2025mm
  • Mobile Stand/Wall Mounting
  • 3840
  • 600
  • 22
  • 1000000:1
  • 170°/170°
  • Front
  • Android 11.0,4+32G
  • AC:100V~240V, 50/60Hz
  • 2450
  • 820
  • -20 ~ 60
  • -10 ~ 50
  • 10 ~ 90
  • 10 ~ 90
  • SR163COBVT-FSN
  • 163”
  • 1920*1080
  • 16:9
  • Infrared touch
  • 3623 x 2161 x 45
    Bottom Thickness 47mm
  • 3600 x 2025mm
  • Mobile Stand/Wall Mounting
  • 3840
  • 600
  • 22
  • 1000000:1
  • 170°/170°
  • Front
  • Android 11.0,4+32G
  • AC:100V~240V, 50/60Hz
  • 2450
  • 820
  • -20 ~ 60
  • -10 ~ 50
  • 10 ~ 90
  • 10 ~ 90
  • S216COBVB-USN
  • 216”
  • 3840*2160
  • 16:9
  • No
  • 4810 x 2830 x 31
    Bottom Thickness 47mm
  • 4800 x 2700mm
  • Wall Mounting
  • 3840
  • 600
  • 22
  • 1000000:1
  • 170°/170°
  • Front
  • Android 11.0,4+32G
  • AC:100V~240V, 50/60Hz
  • 4600
  • 1550
  • -20 ~ 60
  • -10 ~ 50
  • 10 ~ 90
  • 10 ~ 90
